LD490EQG-FNA1 LG Display 49" 3840×2160 700cd/m2 INDUSTRIAL LCD DISPLAY

Name: LD490EQGFNA1 LG Display 49quot 38402160 700cdm2 INDUSTRIAL LCD DISPLAY
Brand: LG Display
Price: 1 USD

Wholesale LD490EQG-FNA1 LG Display 49" 3840×2160 700cd/m2 INDUSTRIAL LCD DISPLAY from china suppliers

Brand Name : LG Display

Model Number : LD490EQG-FNA1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 120PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LD490EQG-FNA1

BRAND : LG Display

SIZE : 49 inch

BRIGHTNESS : 700CD/M2

Lamp Type : WLED

RESOLUTION : 3840(RGB)×2160 (UHD) 90PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C

Contact Now

LG Display LD490EQG-FNA1 Application Details

Basic Information :	Brand LD490EQG-FNA1Model Type a-Si TFT-LCD , LCM Used For Screen Size 49 inch Alias LD490EQG (FN)(A1)
Environment :	Storage Temp. -20 ~ 60 °C Operating Temp. 0 ~ 50 °C

LG Display LD490EQG-FNA1 Mechanical Details

Pixel Features :	Resolution 3840(RGB)×2160, UHD Dot Pitch(mm) 0.09321×0.27963 (H×V) Pixel Format RGB Vertical Stripe Pixel Pitch(mm) 0.27963×0.27963 (H×V) [90PPI]
Mechanical Size :	Active Area(mm) 1073.8(H) × 604(V) Bezel Area(mm) 1078.8(H) × 609(V) Outline Dim.(mm) 1098.6(H) × 633.3(V) Depth(mm) 19.4/27.0 (Typ./Max.)
Outline Features :	Form Style Flat Rectangle Shape Style Aspect Ratio 16:9 (H:V) Orientation Landscape / Portrait
Other Spec :	Weight 12.0/13.2Kgs (Typ./Max.) Treatment Antiglare (Haze 3%), Hard coating (2H)

LG Display LD490EQG-FNA1 Optical Details

Basic Information :	Luminance(cd/m²) 700 (Typ.) Contrast Ratio 1100:1 (Typ.) (Transmissive) Viewing Angle 89/89/89/89 (Min.)(CR≥10) Display Mode IPS, Normally Black, Transmissive Best View on Symmetry Response(ms) 13/12 (Typ.)(Tr/Td)
Color Performance :	White Coordinate Wx:0.279; Wy:0.292 Display Colors 1.07B (10-bit) Color Temperature 9972K White Uniformity 1.54 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio 70% sRGB 94% coverage Adobe RGB 72% coverage DCI-P3 72% coverage Rec.2020 52% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Dispaly Performance :	Outdoor Visibility Sunlight Readable Transmissivity -

LG Display LD490EQG-FNA1 Interface Detail

Signal Electrical :	Voltage Supply 12.0V (Typ.) Current Supply 1.13/1.47A (Typ./Max.) Consumption 13.6/27.5W (Typ./Max.)
Signal Type :	EPI Logic Voltage -
Interface Features :	Position - Type Connector
Interface Detail :	Brand Model Pitch Pins Quantity Pin Configuration 68 pins 2 pcs

LG Display LD490EQG-FNA1 Backlight Details

Backlight Features :	Type WLED Quantity - Position Edge light type Replacement - Shape - Life Time 50K(Min.) (Hours)
Lamp Electrical :	Voltage Supply 132.4±6.6V Current Supply 100mA (Typ.) Consumption 75.5/79.2W (Typ./Max.)
Interface Features :	Position - Type Connector
Interface Detail :	Brand Model Pitch Pins Quantity Pin Configuration UJU HS100-L08N-N62 1.0 mm 8 pins 1 pcs BLE-8PINS-CCCNNNNA UJU HS100-L08N-N62-A 1.0 mm 8 pins 1 pcs BLE-8PINS-ANNNNCCC
Backlight Driver :	No

LG Display LD490EQG-FNA1 Packing Details

Package Box :	Quantity	Weight	Box Size
Package Box :	18 pcs / box	-	1300×1140×930 mm (L×W×H)

Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
