Home > Industrial TFT Display >

DMC-16230NY-LY-EEE-EGN Kyocera 3.8INCH LCM 16×2RGB 60NITS YG-LED INDUSTRIAL LCD DISPLAY

Product Categories

Sapientia Display Co.,LIMITED

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

DMC-16230NY-LY-EEE-EGN Kyocera 3.8INCH LCM 16×2RGB 60NITS YG-LED INDUSTRIAL LCD DISPLAY

Name: DMC16230NYLYEEEEGN Kyocera 38INCH LCM 162RGB 60NITS YGLED INDUSTRIAL LCD DISPLAY
Brand: Kyocera
Price: 1 USD

Wholesale DMC-16230NY-LY-EEE-EGN Kyocera 3.8INCH LCM 16×2RGB 60NITS YG-LED INDUSTRIAL LCD DISPLAY from china suppliers

Brand Name : Kyocera

Model Number : DMC-16230NY-LY-EEE-EGN

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/WESTERNUNION/ESCROW

Supply Ability : 300PCS

Delivery Time : 1-2day

Packaging Details : STANDARD PACKING

BRAND : Kyocera

MODEL NUMBER : DMC-16230NY-LY-EEE-EGN

SIZE : 3.8INCH

RESOLUTION : 16×2RGB

BRIGHTNESS : 60 cd/m² (Min.)

Signal Interface : 8-bit parallel , 14 pins Pad

Lamp Type : 2S24P YG-LED , Without Driver

Environment : Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 70 °C

Contact Now

Kyocera DMC-16230NY-LY-EEE-EGN Application Details

Basic Detail :	Manufacturer DMC-16230NY-LY-EEE-EGNModel Name Panel Type STN-LCD , LCM Another Name - Panel Size 3.8 inch Designed For
Maximum Ratings :	OP Temperature 0 ~ 50 °C ST Temperature -20 ~ 70 °C RoHS -Vibration Level

Kyocera DMC-16230NY-LY-EEE-EGN Optical Details

Basic Detail :	Luminance 60 cd/m² (Min.) Contrast Ratio 12:1 (Typ.) (Transmissive) Good View at 6 o'clock Response Speed 130/180 (Typ.)(Tr/Td) ms Viewing Angle 40/40/50/50 (Typ.)(CR≥2) Operating Mode STN, Yellow/Green (Positive), Transmissive
Color Performance :	Chromaticity - Support Color Monochrome

Kyocera DMC-16230NY-LY-EEE-EGN Mechanical Details

Display Characters :	Numbers of Char. 16 characters × 2 lines Char. Format 5×7 dots + cursor Char. Size 4.84×8.06 mm (W×H) Char. Pitch 6.00×10.0 mm (W×H)
Physical Size :	Active Viewing 94.84(W)×20(H) mm Overall Dim. 122(W)×44(H) mm Bezel Opening 99.0(W)×24.0(H) mm Overall Depth 14.6 (Max.) mm
Outline Features :	Form Shape Flat Rectangle Orientation - Aspect Ratio(W:H) >3:1 Shape Style
Other Detail :	Mass 75.0g (Max.) Surface -

Kyocera DMC-16230NY-LY-EEE-EGN Electronics Details

Driver IC :	Built-in NT3881
Driving Method :	Duty: 1/16 , Bias: 1/4.5

Kyocera DMC-16230NY-LY-EEE-EGN Interface Detail

Signal Electrical :	Input Current 1.8/3.0V (Typ./Max.) Input Voltage 5.0V (Typ.)(VCC) Consumption - Signal Interface 8-bit parallel
Interface Features :	Position - Type Pad
Interface Detail :	Brand Model Pitch Pins Amount Pin Assignment 2.54 mm 14 pins 1 pcs

Kyocera DMC-16230NY-LY-EEE-EGN Lightting Details

Lamp Features :	Lamp Type YG-LED Amount 2S24P Position Edge light type Exchange - Lamp Shape Array Lamp Life -
Lamp Electrical :	Input Voltage 4.0±0.2V Input Current 240mA (Typ.)
Backlight Driver :	No

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
