N156BGE-E41 Innolux 15.6" 1366(RGB)×768 200 cd/m² INDUSTRIAL LCD DISPLAY

Name: N156BGEE41 Innolux 156quot 1366RGB768 200 cdm INDUSTRIAL LCD DISPLAY
Brand: INNOLUX
Price: 1 USD

Wholesale N156BGE-E41 Innolux 15.6" 1366(RGB)×768 200 cd/m² INDUSTRIAL LCD DISPLAY from china suppliers

Brand Name : INNOLUX

Model Number : N156BGE-E41

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 100PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : N156BGE-E41

BRAND : INNOLUX

SIZE : 15.6 inch

BRIGHTNESS : 200 cd/m² (Typ.)

Lamp Type : WLED

RESOLUTION : 1366(RGB)×768 [WXGA] 100PPI

VIEWING ANGLEG : 45/45/20/45 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

Innolux N156BGE-E41 Application Details

Basic Info :	Panel Brand		Panel Model	N156BGE-E41 23 Compatible
	Diagonal Size	15.6"	Application
	Panel Type	a-Si TFT-LCD , LCM	Model Alias	CMN15BF
Reliability :	Operating Temp.	0 ~ 50 °C	Storage Temp.	-20 ~ 60 °C

Innolux N156BGE-E41 Mechanical Details

Pixel Features :	Pixel Format	1366(RGB)×768 [WXGA]	Dot Pitch	0.084×0.252 mm (H×V)
Pixel Features :	Configuration	RGB Vertical Stripe	Pixel Pitch	0.252×0.252 mm (H×V) [100PPI]
Mechanical Size :	Display Area	344.232×193.536 mm (H×V)	Bezel Area	347.36×196.59 mm (H×V)
Mechanical Size :	Outline Dim.	359.5×223.8 mm (H×V)	Outline Depth	3.5/3.8 (Typ.Max.) mm
Outline Features :	Form Factor	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio	16:9 (H:V)	Shape Style	Flat (PCBA Flat, T3.4~4.0mm)
Holes & Brackets :	Face mounting holes (8 pcs) on up, down slugs
Other Features :	Weight	410±15g	Surface	Glare (Haze 0%), Hard coating (3H)

Innolux N156BGE-E41 Optical Details

Basic Information :	Brightness	200 cd/m² (Typ.)	Contrast Ratio	500:1 (Typ.) (Transmissive)
	Viewing Angle	45/45/20/45 (Typ.)(CR≥10)	Optical Mode	TN, Normally White, Transmissive
	Viewing Direction	6 o'clock	Response Time	3/8 (Typ.)(Tr/Td) (ms)
Color Performance :	Chromaticity	Wx:0.313; Wy:0.329	Color Numbers	262K (6-bit)
Color Performance :	Color Temperature	6485K	White Uniformity	1.25 (Max.)(5 points)
1931 Color Gamlt :	NTSC Ratio	49%	sRGB	68% coverage
	Adobe RGB	51% coverage	DCI-P3	51% coverage
	Rec.2020	36% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

Innolux N156BGE-E41 Backlight Details

Back-light Features:	Lamp Shape	-	Lamp Type	WLED	Life Time	15K(Min.) (Hours)
Back-light Features:	Replacement	-	Amount	-	Position	Edge light type
Interface Features :	Type	Included in panel signal interface	Position	-	Lamp Driver	With LED Driver
Driver Electrical :	Voltage Input	5.0/12.0/21.0V (Min./Typ./Max.)		Current Input	116/145/160mA (Min./Typ./Max.)
Driver Electrical :	Consumption	1.92W (Max.)

Innolux N156BGE-E41 Interface Details

Signal Systerm :	eDP (1 Lane)			Logic Voltage	-
Signal Electrical :	Voltage Input	3.3V (Typ.)		Current Input	300/340mA (Typ./Max.)
Signal Electrical :	Consumption	1.0W (Max.)
Interface Features :	Type	Connector	Position
Connector Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Connector Detail :	I-PEX	20455-030E-12	0.5 mm	30 pins	1 pcs	EDP-30P1L-030A

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
