AUO B156HAN04.2 Application Features
| Basic Information : | Manufacturer | Panel Model | Panel Type | Alias |
| | B156HAN04.2 | a-Si TFT-LCD , LCM | AUO42ED |
| Environment : | RoHS State | Operating Temp. | Storage Temp. | Vibration Level |
| | 0 ~ 50 °C | -20 ~ 60 °C | - |
AUO B156HAN04.2 Optical Features
| Basic Information : | Luminance (cd/m²) | Viewing Angle (L/R/U/D) | Response Time (ms) |
| 300 (Typ.) | 85/85/85/85 (Typ.)(CR≥10) | 25 (Typ.)(Tr+Tf) |
| Best View on | Display Mode | Contrast Ratio |
| Symmetry | AHVA, Normally Black, Transmissive | 800 : 1 (Typ.) (Transmissive) |
| Dispaly Color : | Color Temperature | Display Colors | White Coordinate |
| 6485K | 16.7M (8-bit) | X:0.313; Y:0.329 |
| 1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 74% | 95% | 74% |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks |
| 76% | 55% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| White Variation : | 1.25/1.60 (Max.)(5/60 points) |
AUO B156HAN04.2 Mechanical Features
| Panel Size : | 15.6" |
| Pixel Features : | Pixel Format | Pixel Configuration | Pixel Pitch (mm) | Dot Pitch (mm) |
| 1920(RGB)×1080 [FHD] | RGB Vertical Stripe | 0.17925×0.17925 [141PPI] | 0.05975×0.17925 |
| Mechanical Size : | Active Area (mm) | Bezel Area (mm) | Outline Dimension (mm) | Outline Depth (mm) |
| 344.16(H) × 193.59(V) | - | 359.5(H) × 223.8(V) | 3.05/3.2 (Typ./Max.) mm |
| Outline Features : | Form Factor | Orientation | Aspect Ratio | Shape Style |
| Flat Rectangle | Landscape type | 16:9 (H:V) | Slim (PCBA Flat, T≤3.2mm) |
| Mounting : | Face mounting holes (8 pcs) on up, down slugs |
| Other Detail : | Weight | Panel Cover | Treatment |
| 350g (Max.) | - | Antiglare |
AUO B156HAN04.2 Electronics Features
| Reverse Scan : | No |
| Vertical Frequency : | 120Hz |
| Power Consumption : | 7.4W (Typ.) |
AUO B156HAN04.2 Backlight Features
| Lamp Features: | Type | Position | Quantity | Shape | Life(Hours) | Lamp Exchange |
| WLED | Edge light type | - | - | 15K(Min.) | - |
| Interface Features : | Position | Backlight Driver | Type |
| - | With LED Driver | Included in panel signal interface |
| Driver Electrical : | Voltage Supply | Current Supply | Power Consumption |
| 5.0/12.0/21.0V (Min./Typ./Max.) | - | 4.7W (Max.) |
AUO B156HAN04.2 Interface Features
| Panel Driving Electrical : | Voltage Supply | Current Supply | Power |
| 3.3V (Typ.) | 900mA (Max.) | 2.7W (Typ.) |
| Interface Features : | Position | Signal | Type |
| | eDP (2 Lanes) | Connector |
| Connector Detail : | Brand | Model | Pin Pitch | Pin Amount | Quantity | Configuration |
| I-PEX | 20455-030E-76B | 0.5 mm | 30 pins | 1 pcs | EDP-30P2L-021ZZ |
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 344.16(W)×193.59(H) mm, outline size of 359.5(W)×223.8(H)×3.2(D) mm, with surface treament of Antiglare, net weight of 350g (Max.), shape stype of Slim (PCBA Flat, T≤3.2mm). As a AHVA, Normally Black, Transmissive LCM product, B156HAN04.2 can provides 300 cd/m² display brightness 800:1 transimissive contrast ratio, 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 25 (Typ.)(Tr+Tf) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 15K hours, With LED Driver. B156HAN04.2 utilizes eDP (2 Lanes) as it's signal inputting systerm, which connected by 30 pins Connector with power supply voltage of 3.3V (Typ.).
