OPTREX DMF5005NY-LY Mechanical Details
| Pixel Features : | Resolution | 240×64 | Dot Pitch(mm) | 0.53×0.53 (H×V) |
| Pixel Format | Rectangle | Pixel Pitch(mm) | 0.53×0.53 (H×V) [47PPI] |
| Mechanical Size : | Active Area(mm) | 127.16(H) × 33.88(V) | Bezel Area(mm) | 132.0(H) × 39.0(V) |
| Outline Dim.(mm) | 180(H) × 65(V) | Depth(mm) | 17.6 |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | >3:1 (H:V) | Orientation | Landscape type |
| Other Spec : | Weight | 170g (Max.) | Treatment |
OPTREX DMF5005NY-LY Optical Details
| Basic Information : | Luminance(cd/m²) | 45 (Min.) | Contrast Ratio | 7:1 (Typ.) (Transmissive) |
| Viewing Angle | 32/32/36/33 (Typ.)(CR≥2) | Display Mode | STN, Yellow/Green (Positive), Transmissive |
| Best View on | 6 o'clock | Response(ms) | 160/160 (Typ.)(Tr/Td) |
| Color Performance : | White Coordinate | - | Display Colors | Monochrome (1-bit) |
OPTREX DMF5005NY-LY Electronics Details
| Frame Rate : | 70Hz |
| Driver IC : | Built-in T6963C-0101 |
| Driving Method : | Duty: 1/64 , Bias: 1/9 |
OPTREX DMF5005NY-LY Interface Details
| Signal Electrical : | Voltage Supply | 5.0V (Typ.)(VCC) | Current Supply | 7.0/20.0mA (Typ./Max.)(ICC) |
| Signal Type : | 8-bit parallel | Signal Voltage | - |
| Interface Features : | Position | - | Type | Pad |
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| | | 1 pcs | 22 pins | 2.5 mm |
OPTREX DMF5005NY-LY Backlight Details
| Backlight Features: | Shape | - | Type | YG-LED | Position | Edge light type |
| Replacement | - | Quantity | - | Life Time | - |
| Lamp Electrical : | Voltage Supply | 4.1±0.3V | Current Supply | |
| Backlight Driver : | No |
