LQ116 Series LQ116T1JW03 LQ116M1JX07 LQ116M1JX06 LQ116M1JW02 LQ116K1JX01
Sharp LQ116M1JX06 Mechanical Details
| Pixel Features : | Resolution | 1920(RGB)×1080, FHD | Dot Pitch(mm) | 0.0445×0.1335 (H×V) |
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.1335×0.1335 (H×V) [190PPI] |
| Mechanical Size : | Active Area(mm) | 256.32(H) × 144.18(V) | Bezel Area(mm) | - |
| Outline Dim.(mm) | 263.4(H) × 159(V) | Depth(mm) | 2.35±0.2 |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | Slim (PCBA Bent, T≤3.0mm) |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape type |
| Mounting : | Without |
| Other Spec : | Weight | 155/166g (Typ./Max.) | Treatment | Glare (Haze 0%), Hard coating (3H) |
Sharp LQ116M1JX06 Optical Details
| Basic Information : | Luminance(cd/m²) | 300 (Typ.) | Contrast Ratio | 1500:1 (Typ.) (Transmissive) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Display Mode | IPS, Normally Black, Transmissive |
| Best View on | Symmetry | Response(ms) | 22 (Typ.)(G to G); 30 (Typ.)(Tr+Td) |
| Color Performance : | White Coordinate | X:0.313; Y:0.329 | Display Colors | 16.7M (8-bit) |
| Color Temperature | 6485K | White Uniformity | 1.25/1.40 (Typ./Max.)(5 points) |
| 1931 Color Gamlt : | NTSC Ratio | 71% | sRGB | 100% coverage |
| Adobe RGB | 74% coverage | DCI-P3 | 74% coverage |
| Rec.2020 | 53% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
Sharp LQ116M1JX06 Interface Details
| Signal Electrical : | Voltage Supply | 3.3V (Typ.) | Current Supply | 227/375mA (Typ./Max.) |
| Consumption | 0.75/1.24W (Typ./Max.) |
| Signal Type : | eDP (2 Lanes), eDP1.3, HBR1 (2.7G/lane) | Signal Voltage | - |
| Interface Features : | Position | | Type | Connector |
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| I-PEX | 20455-030E-76 | 1 pcs | 30 pins | 0.5 mm | EDP-30P2L-020AA |
Sharp LQ116M1JX06 Electronics Details
| Frame Rate : | 60Hz |
| Reverse Scan : | No |
Sharp LQ116M1JX06 Backlight Details
| Backlight Features: | Shape | - | Type | WLED | Position | Edge light type |
| Replacement | - | Quantity | - | Life Time | 10K(Typ.) (Hours) |
| Interface Features : | Position | - | Type | Included in panel signal interface |
| Backlight Driver : | With LED Driver |
| Driver Electrical : | Voltage Supply | 5.0/12.0/21.0V (Min./Typ./Max.) | Current Supply | 227/251mA (Typ./Max.) |
| Consumption | 2.72/3.0W (Typ./Max.) |
Sharp LQ116M1JX06 Packing Details
| Package Box : | Quantity | Weight | Box Size |
| 40 pcs / box | 11 Kgs | 554×360×281 mm (L×W×H) |
