HJ070NA-13A Innolux 7.0" 1024(RGB)×600 250 cd/m² INDUSTRIAL LCD DISPLAY

Sapientia Display Co.,LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

HJ070NA-13A Innolux 7.0" 1024(RGB)×600 250 cd/m² INDUSTRIAL LCD DISPLAY

Brand Name : INNOLUX

Model Number : HJ070NA-13A

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 500PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : HJ070NA-13A

BRAND : INNOLUX

SIZE : 7.0INCH

BRIGHTNESS : 250CD/M2

Lamp Type : WLED

RESOLUTION : 1024(RGB)×600 (WSVGA) 169PPI

VIEWING ANGLEG : 70/75/75/75 (Typ.)(CR≥10)

TEMPERATURE RANGE : Storage Temp.: -20 ~ 60 °C Operating Temp.: -10 ~ 50 °C

Contact Now

Innolux HJ070NA-13A Application Features

Basic Information : Manufacturer Panel Model Panel Type Alias
HJ070NA-13A a-Si TFT-LCD , LCM -
Environment : RoHS State Operating Temp. Storage Temp. Vibration Level
-10 ~ 50 °C -20 ~ 60 °C

Innolux HJ070NA-13A Optical Features

Basic Information : Luminance (cd/m²) Viewing Angle (L/R/U/D) Response Time (ms)
250 (Typ.) 70/75/75/75 (Typ.)(CR≥10) 10/15 (Typ.)(Tr/Td)
Best View on Display Mode Contrast Ratio
6 o'clock TN, Normally White, Transmissive 700 : 1 (Typ.) (Transmissive)
Dispaly Color : Color Temperature Display Colors White Coordinate
6638K 262K/16.7M (6-bit / 6-bit + Hi-FRC) X:0.310; Y:0.330
White Variation : 1.33/1.43 (Typ./Max.)(9 points)

Innolux HJ070NA-13A Mechanical Features

Panel Size : 7.0"
Pixel Features : Pixel Format Pixel Configuration Pixel Pitch (mm) Dot Pitch (mm)
1024(RGB)×600 [WSVGA] RGB Vertical Stripe 0.150×0.150 [169PPI] 0.050×0.150
Mechanical Size : Active Area (mm) Bezel Area (mm) Outline Dimension (mm) Outline Depth (mm)
153.6(H) × 90(V) 156.4(H) × 92.8(V) 165.75(H) × 105.39(V) 2.45±0.2 mm
Outline Features : Form Factor Orientation Aspect Ratio Shape Style
Flat Rectangle Landscape type 17:10 (H:V)
Mounting : Without
Other Detail : Weight Panel Cover Treatment
92.8g (Typ.)

Innolux HJ070NA-13A Electronics Features

Reverse Scan : Yes (U/D, L/R)
Vertical Frequency : 60Hz
Power Consumption : 1.834W (Typ.)

Innolux HJ070NA-13A Backlight Features

Lamp Features: Type Position Quantity Shape Life(Hours) Lamp Exchange
WLED Edge light type - - 15K(Min.) -
WLED Electrical : Voltage Supply Current Supply Power
9.3/10.2V (Typ./Max.) 160/200mA (Typ./Max.) 1.488W (Typ.)
Interface Features : Position Backlight Driver Type
- No Included in panel signal interface

Innolux HJ070NA-13A Interface Features

Panel Driving Electrical : Voltage Supply Current Supply Power
3.3/11.0/20.0/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL) 38/20/0.25/0.25mA (Typ.)(IDVDD/IAVDD/IGH/IGL) 346mW
Interface Features : Position Signal Type
- LVDS (1 ch, 6/8-bit) FPC
FPC Detail : Brand Model Pin Pitch Pin Amount Quantity Configuration
0.5 mm 40 pins 1 pcs LVDS-40P1C8B-050A

Innolux HJ070NA-13A Packing Features

Package Box : Quantity Weight Box Size
50 pcs / box 7.21 Kgs (Typ.) 530×355×255 mm (L×W×H)

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.

HJ070NA-13A Innolux 7.0" 1024(RGB)×600 250 cd/m² INDUSTRIAL LCD DISPLAYHJ070NA-13A Innolux 7.0" 1024(RGB)×600 250 cd/m² INDUSTRIAL LCD DISPLAY


Product Tags:

WVGA Industrial Lcd Panel



Capacitive TFT Touch Panel



VGA Lcd Display Panels


Wholesale HJ070NA-13A Innolux 7.0" 1024(RGB)×600 250 cd/m² INDUSTRIAL LCD DISPLAY from china suppliers

HJ070NA-13A Innolux 7.0" 1024(RGB)×600 250 cd/m² INDUSTRIAL LCD DISPLAY Images
