LM270WR2-SPA1 LG Display 27.0" 3840(RGB)×2160 350 cd/m² INDUSTRIAL LCD DISPLAY

Brand Name : LG DISPLAY

Model Number : LM270WR2-SPA1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 800PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LM270WR2-SPA1

BRAND : LG DISPLAY

Lamp Type : WLED

RESOLUTION : 3840(RGB)×2160 [UHD] 163PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

BRIGHTNESS : 350CD/M2

SIZE : 27.0INCH

Contact Now

LG Display LM270WR2-SPA1 Application Features

Basic Information : Brand Name Model Name Type Model Alias
LM270WR2-SPA1 a-Si TFT-LCD , LCM LM270WR2 (SP)(A1)
Maximum Ratings : RoHS Operating Temperature Storage Temperature Vibration Level
0 ~ 50 °C -20 ~ 60 °C

LG Display LM270WR2-SPA1 Mechanical Features

Screen Size : 27.0"
Pixel Features : Pixel Number Pixel Format Dot Pitch (H×V) Pixel Pitch (H×V)
3840(RGB)×2160, UHD RGB Vertical Stripe 0.05175×0.15525 mm 0.15525×0.15525 mm [163PPI]
Mechanical Size : Display Area (H×V) Bezel Opening (H×V) Overall Dimension (H×V) Overall Depth
596.16×335.34 mm 602.0×340.4 mm 630×368.2 mm 13.3/18.5 (Typ./Max.) mm
Outline Features : Form Shape Aspect Ratio (H:V) Orientation Shape Style
Flat Rectangle 16:9 Landscape type Normal bezel
Other Spec : Mass Panel Cover Surface Treatment
3.22/3.38Kgs (Typ./Max.) - Antiglare, Hard coating (3H)
Holes & Brackets : Side mounting holes (4-M3) on left, right bezel

LG Display LM270WR2-SPA1 Optical Features

Basic Information : Luminance Work Mode Contrast Ratio
350 cd/m² (Typ.) IPS, Normally Black, Transmissive 1000:1 (Typ.) (Transmissive)
Good View at Viewing Angle Response Time
Symmetry 89/89/89/89 (Typ.)(CR≥10) 14 (Typ.)(G to G) (ms)
Dispaly Color : Color Temperature: Support Color Color Coordinate
6485K 1.07B (8-bit + Hi-FRC) X:0.313; Y:0.329
1931 Color Gamlt : NTSC Ratio sRGB Coverage Adobe RGB Coverage
78% 100% 78%
DCI-P3 Coverage Rec.2020 Coverage Remarks
81% 58% sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
White Uniformity : 1.33 (Max.)(9 points)

LG Display LM270WR2-SPA1 Backlight Features

Back-light Features: Type Position Life(Hours) Amount Shape Replacement
WLED Edge light type (Bottom side) 30K(Min.) 17S4P 4 strings -
WLED Electrical : Input Voltage Input Current Power Consumption
51.9V (Typ.) 120mA (Typ.) 24.9/26.5W (Typ./Max.)
Interface Features : WLED Driver State Physical Type Interface Position
No Connector
Interface Detail Brand Name Model Name Amount Pins Pin Pitch Pin Configuration
JST SM06B-SHJH(HF) 1 pcs 6 pins 1.0 mm BLE-6PINS-CCAACC

LG Display LM270WR2-SPA1 Interface Features

Signal Electrical : Input Voltage Input Current Power Consumption
10.0V (Typ.) 570/713mA (Typ./Max.) 5.7/7.13W (Typ./Max.)
Interface Features : Signal Type Physical Type Interface Position
eDP (4 Lanes) Connector
Interface Detail : Brand Name Model Name Amount Pins Pin Pitch Pin Configuration
LS Mtron GT05Q-30S-H10-MN 1 pcs 30 pins 0.5 mm EDP-30P4L-050A

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.

LM270WR2-SPA1 LG Display 27.0" 3840(RGB)×2160 350 cd/m² INDUSTRIAL LCD DISPLAY
